Liquid-cooled Solar Storage Batteries Cabinet

Liquid-cooled Solar Storage Batteries Cabinet

418kWh



The ECO-B418LP-1A is a standalone, free-standing solar storage batteries solution designed to deliver superior efficiency and performance. Equipped with state-of-the-art liquid cooling technology at the pack level and temperature balancing at the cell level, this system ensures exceptional temperature consistency, maintaining a temperature difference of less than 3°C between cells. This technology not only enhances the operational stability but also maximizes the lifespan of the battery, making it an ideal choice for long-term energy storage applications.

Its modular design provides flexibility for future expansion, allowing seamless parallel connections to accommodate increasing energy requirements. When integrated with a centralized Power Conversion System (PCS), the ECO-B418LP-1A forms a high-density, cost-efficient Energy Storage System (ESS) that maximizes both space and performance, making it suitable for a wide range of commercial, industrial, and residential applications.

KEY FEATURES

Compact & Versatile Design

With a space-efficient 1.7m² footprint, this system delivers high energy storage capacity in a compact, adaptable form, making it ideal for large commercial senanios.

High Integration for MV/HV Applications

Multiple units can be connected in parallel, enabling MV/HV connections and integration with PCS-boost containers for large-scale, high-density ESS projects.

Seamless Expansion & Grid Access

Its modular design allows for easy scaling and flexible grid integration, adapting to growing energy storage needs.

Long-Term Durability

With over 8,000 charge-discharge cycles, this system ensures long-lasting, reliable performance, providing excellent value and durability over time.

Efficient Liquid Cooling

Features a sophisticated liquid cooling system with in-PACK duct design for high cooling efficiency, optimizing system performance while minimizing energy consumption.

Superior Safety

NOVEC1230/aerosol fire protection ensures enhanced safety by preventing heat diffusion and mitigating thermal runaway risks.

SPECIFICATION

Battery Type LFP 314Ah
Battery System 418kWh
Voltage Range 1164.8-1497.6Vdc
Rated Voltage 1331.2Vdc
Ingress Rating IP55
Cycle Life ≥8,000 cycles
Certification UN38.3, IEC62477-1, IEC61000, IEC62619, IEC63056, UL9540A

APPLICATION SCENARIOS

The ECO-B418LP-1A 418 kWh liquid-cooled solar storage system is perfect for diverse applications. Engineered for exceptional performance, it offers reliable, sustainable, and efficient energy storage that meets the highest industry standards for your business needs.

Industrial & Commercial Energy Storage

  • Peak shaving & load shifting to reduce electricity costs
  • Backup power supply for uninterrupted operations

Off-Grid & Remote
Areas

  • Reliable energy storage for rural electrification & island microgrids
  • Solar hybrid solutions for off-grid applications

Residential & Community Solar Storage

  • Enables self-consumption & energy independence
  • Supports community microgrid projects with scalable capacity

Renewable Energy Integration

  • Seamless integration with solar & hybrid energy systems
  • Enhances stability & efficiency of renewable power plants
