Hybrid Energy Storage System

Hybrid Energy Storage System

107kWh



The ECO-E107WS by Sunergy Technology is a cutting-edge Hybrid Energy Storage System that combines a lithium battery energy storage system (BESS), hybrid inverter, Heating Ventilation Air Conditioning (HVAC), fire safety system (FSS), and battery control unit (BCU) into a compact, modular, and scalable unit.

Engineered for self-consumption, peak shaving, and backup power, the ECO-E107WS offers exceptional efficiency, easy installation, and flexible scalability to meet the diverse needs of residential and commercial applications.

KEY FEATURES

High Efficiency &
Reliability

  • Round-trip efficiency (RTE) is over 90%, ensuring optimal energy conversion.
  • Depth of discharge (DoD) is over 95%, maximizing battery utilization.

Advanced Safety &
Durability

  • IP55-rated with optimized ventilation, ensuring a 6°C temperature difference.
  • Aerosol-based fire safety system for max. protection.

Compact & Modular
Design

  • Occupies only 0.96㎡, ensuring easy transportation and installation.
  • Supports parallel expansion, allowing scalable energy storage solutions.

Smart & Versatile
O&M

  • Supports various operation modes, including onsite monitoring and cloud management.
  • Ethernet & RS485 connectivity for real-time system monitoring.

Seamless PV & Hybrid Integration

  • PV input voltage range: 150V-850V, compatible with various PV configurations.
  • Hybrid inverter compatibility for enhanced selectivity and flexibility.

Self-Developed
Technology

Integrates self-developed PACK, Battery Management System (BMS), and Energy Management System (EMS), ensuring excellent compatibility and seamless operation.

SPECIFICATION

Battery Type LFP 280Ah
Battery System 107.52kWh / 1P120S
Voltage Range 336~432Vdc
Rated Voltage 384V
Ingress Rating IP55
Cycle Life ≥8,000 cycles
Certification UN38.3, IEC62477, IEC61000, IEC62619, IEC63056, UL9540A
Datasheet

APPLICATION SCENARIOS

The ECO-E107WS Air-cooled Hybrid Energy Storage System is perfect for diverse applications. Experience unmatched reliability and performance, surpassing industry standards to provide sustainable, efficient, and secure energy storage for your business.

Shops

Inns

Clinics

Restaurants
